Specifications: Volkswagen Jetta V 1.9 TDI PDE (105 Hp) DSG 2005, 2006, 2007, 2008, 2009

2006 Volkswagen Jetta V - Photo 1

Volkswagen Jetta V 1.9 TDI PDE (105 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Jetta
Generation Jetta V
Modification (Engine) 1.9 TDI PDE (105 Hp) DSG
Start of production 2005 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 7.6 l/100 km
30.9 US mpg
37.2 UK mpg
13.2 km/l
Fuel consumption (economy) – extra urban 5 l/100 km
47 US mpg
56.5 UK mpg
20 km/l
Fuel consumption (economy) – combined 5.9 l/100 km
39.9 US mpg
47.9 UK mpg
16.9 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.8 sec
Acceleration 0 – 62 mph 11.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.2 sec
Maximum speed 187 km/h
116.2 mph
Emission standard Euro 4
Weight-to-power ratio 12.8 kg/Hp, 78.1 Hp/tonne
Weight-to-torque ratio 5.4 kg/Nm, 185.9 Nm/tonne
Engine specs
Power 105 Hp @ 4000 rpm.
Power per litre 55.4 Hp/l
Torque 250 Nm @ 1900 rpm.
184.39 lb.-ft. @ 1900 rpm.
Engine layout Front, Transverse
Engine Model/Code EA188 / BXE
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 19:1
Number of valves per cylinder 2
Fuel injection system Pump-nozzle (Unit Injector)
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1345 kg
2965.22 lbs.
Max. weight 1940 kg
4276.97 lbs.
Max load 595 kg
1311.75 lbs.
Trunk (boot) space – minimum 527 l
18.61 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4554 mm
179.29 in.
Width 1781 mm
70.12 in.
Height 1459 mm
57.44 in.
Wheelbase 2578 mm
101.5 in.
Front track 1534 mm
60.39 in.
Rear (Back) track 1512 mm
59.53 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Coil spring, Wishbone, Transverse stabilizer
Rear suspension Independent multi-link suspension, Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16
Wheel rims size 6.5 x 16
