Specifications: Volkswagen Jetta VI (facelift 2014) 1.2 TSI (105 Hp) 2014, 2015, 2016, 2017, 2018

2014 Volkswagen Jetta VI (facelift 2014) - Photo 1

Volkswagen Jetta VI (facelift 2014) 1.2 TSI (105 Hp) – Full specifications
General information
Brand Volkswagen
Model Jetta
Generation Jetta VI (facelift 2014)
Modification (Engine) 1.2 TSI (105 Hp)
Start of production 2014 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – extra urban 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
Fuel consumption (economy) – combined 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
CO2 emissions 117 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.7 sec
Acceleration 0 – 62 mph 10.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.2 sec
Maximum speed 194 km/h
120.55 mph
Emission standard Euro 6
Weight-to-power ratio 12.5 kg/Hp, 80.2 Hp/tonne
Weight-to-torque ratio 7.5 kg/Nm, 133.7 Nm/tonne
Engine specs
Power 105 Hp @ 4500-5500 rpm.
Power per litre 87.7 Hp/l
Torque 175 Nm @ 1400-4000 rpm.
129.07 lb.-ft. @ 1400-4000 rpm.
Engine layout Front, Transverse
Engine Model/Code CBZB
Engine displacement 1197 cm3
73.05 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 2
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.9 l
4.12 US qt | 3.43 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1309 kg
2885.85 lbs.
Max. weight 1800 kg
3968.32 lbs.
Max load 491 kg
1082.47 lbs.
Trunk (boot) space – minimum 510 l
18.01 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4659 mm
183.43 in.
Width 1778 mm
70 in.
Height 1482 mm
58.35 in.
Wheelbase 2651 mm
104.37 in.
Front track 1535 mm
60.43 in.
Rear (Back) track 1538 mm
60.55 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
Wheel rims size 6.5J x 16
