| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Multivan |
| Generation | Multivan (T4) |
| Modification (Engine) | 2.5 TDI (150 Hp) |
| Start of production | 1990 year |
| End of production | 2003 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 18.1 sec |
| Acceleration 0 – 62 mph | 18.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 17.2 sec |
| Maximum speed | 181 km/h 112.47 mph |
| Weight-to-power ratio | 13.3 kg/Hp, 75 Hp/tonne |
| Weight-to-torque ratio | 6.8 kg/Nm, 147.4 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 4000 rpm. |
| Power per litre | 61 Hp/l |
| Torque | 295 Nm @ 1900 rpm. 217.58 lb.-ft. @ 1900 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | AHY, AXG |
| Engine displacement | 2461 cm3 150.18 cu. in. |
| Number of cylinders | 5 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 19:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | OHC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11.5 l 12.15 US qt | 10.12 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2001 kg 4411.45 lbs. |
| Max. weight | 2660 kg 5864.3 lbs. |
| Max load | 659 kg 1452.85 lbs. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Dimensions | |
| Length | 4789 mm 188.54 in. |
| Width | 1840 mm 72.44 in. |
| Height | 1900 mm 74.8 in. |
| Wheelbase | 2920 mm 114.96 in. |
| Front track | 1589 mm 62.56 in. |
| Rear (Back) track | 1554 mm 61.18 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Independent coil spring |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Power steering | Hydraulic Steering |
| Tires size | 215/60 R16 H |
| Wheel rims size | 16 |
