| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Multivan |
| Generation | Multivan (T5, facelift 2009) |
| Modification (Engine) | 2.0 TDI (140 Hp) BMT DSG |
| Start of production | 2009 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 9.3 l/100 km 25.3 US mpg 30.4 UK mpg 10.8 km/l |
| Fuel consumption (economy) – extra urban | 6.5 l/100 km 36.2 US mpg 43.5 UK mpg 15.4 km/l |
| Fuel consumption (economy) – combined | 7.5 l/100 km 31.4 US mpg 37.7 UK mpg 13.3 km/l |
| CO2 emissions | 198 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14.7 sec |
| Acceleration 0 – 62 mph | 14.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 14 sec |
| Maximum speed | 172 km/h 106.88 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 14.8 kg/Hp, 67.5 Hp/tonne |
| Weight-to-torque ratio | 6.1 kg/Nm, 163.9 Nm/tonne |
| Engine specs | |
| Power | 140 Hp @ 3500 rpm. |
| Power per litre | 71.1 Hp/l |
| Torque | 340 Nm @ 1750-2500 rpm. 250.77 lb.-ft. @ 1750-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | CCHA |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 7 l 7.4 US qt | 6.16 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2075 kg 4574.59 lbs. |
| Max. weight | 3000 kg 6613.87 lbs. |
| Max load | 925 kg 2039.28 lbs. |
| Dimensions | |
| Length | 4892 mm 192.6 in. |
| Width | 1904 mm 74.96 in. |
| Height | 1970 mm 77.56 in. |
| Wheelbase | 3000 mm 118.11 in. |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DSG |
| Front brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
