Specifications: Volkswagen Passat Alltrack (B8, facelift 2019) 2.0 TDI (200 Hp) 4MOTION DSG 2020, 2021, 2022, 2023

2020 Volkswagen Passat Alltrack (B8, facelift 2019) - Photo 1

Volkswagen Passat Alltrack (B8, facelift 2019) 2.0 TDI (200 Hp) 4MOTION DSG – Full specifications
General information
Brand Volkswagen
Model Passat
Generation Passat Alltrack (B8, facelift 2019)
Modification (Engine) 2.0 TDI (200 Hp) 4MOTION DSG
Start of production 2020 year
End of production 2023 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate), Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 8.2 l/100 km
28.7 US mpg
34.4 UK mpg
12.2 km/l
Fuel consumption at Medium speed (WLTP) 6.0 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel consumption at high speed (WLTP) 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
Fuel consumption at very high speed (WLTP) 6.0 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Combined fuel consumption (WLTP) 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
CO2 emissions (WLTP) 160 g/km
Fuel consumption (economy) – urban (NEDC) 6.1-6.3 l/100 km
38.6 – 37.3 US mpg
46.3 – 44.8 UK mpg
16.4 – 15.9 km/l
Fuel consumption (economy) – extra urban (NEDC) 4.3-4.5 l/100 km
54.7 – 52.3 US mpg
65.7 – 62.8 UK mpg
23.3 – 22.2 km/l
Fuel consumption (economy) – combined (NEDC) 5.0-5.2 l/100 km
47 – 45.2 US mpg
56.5 – 54.3 UK mpg
20 – 19.2 km/l
CO2 emissions (NEDC) 131-137 g/km
Fuel Type Diesel
Maximum speed 228 km/h
141.67 mph
Emission standard Euro 6-ISC-FCM
Weight-to-power ratio 8.2 kg/Hp, 122.4 Hp/tonne
Weight-to-torque ratio 4.1 kg/Nm, 244.8 Nm/tonne
Engine specs
Power 200 Hp
Power per litre 101.6 Hp/l
Torque 400 Nm @ 1750-3500 rpm.
295.02 lb.-ft. @ 1750-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code DTUA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1634 kg
3602.35 lbs.
Max. weight 2280 kg
5026.54 lbs.
Max load 646 kg
1424.19 lbs.
Trunk (boot) space – minimum 639 l
22.57 cu. ft.
Trunk (boot) space – maximum 1769 l
62.47 cu. ft.
Fuel tank capacity 66 l
17.44 US gal | 14.52 UK gal
AdBlue tank 16 l
4.23 US gal | 3.52 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2200 kg
4850.17 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4780-4888 mm
188.19 – 192.44 in.
Width 1853 mm
72.95 in.
Width including mirrors 2083 mm
82.01 in.
Height 1527 mm
60.12 in.
Wheelbase 2788 mm
109.76 in.
Front track 1580-1586 mm
62.2 – 62.44 in.
Rear (Back) track 1563-1569 mm
61.54 – 61.77 in.
Minimum turning circle (turning diameter) 11.7 m
38.39 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17
Wheel rims size 8J x 17
