Specifications: Volkswagen Passat Variant (B5) 1.8 20V (125 Hp) 1997, 1998, 1999, 2000

1997 Volkswagen Passat Variant (B5) - Photo 1

Volkswagen Passat Variant (B5) 1.8 20V (125 Hp) – Full specifications
General information
Brand Volkswagen
Model Passat
Generation Passat Variant (B5)
Modification (Engine) 1.8 20V (125 Hp)
Start of production 1997 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 12.3 l/100 km
19.1 US mpg
23 UK mpg
8.1 km/l
Fuel consumption (economy) – extra urban 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.2 sec
Acceleration 0 – 62 mph 11.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.6 sec
Maximum speed 200 km/h
124.27 mph
Weight-to-power ratio 10.5 kg/Hp, 95.1 Hp/tonne
Weight-to-torque ratio 7.8 kg/Nm, 127.8 Nm/tonne
Engine specs
Power 125 Hp @ 5800 rpm.
Power per litre 70.2 Hp/l
Torque 168 Nm @ 3500 rpm.
123.91 lb.-ft. @ 3500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code ADR, APT, ARG
Engine displacement 1781 cm3
108.68 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 10.3:1
Number of valves per cylinder 5
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1315 kg
2899.08 lbs.
Max. weight 1865 kg
4111.62 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 495 l
17.48 cu. ft.
Trunk (boot) space – maximum 1600 l
56.5 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4675 mm
184.06 in.
Width 1740 mm
68.5 in.
Height 1459 mm
57.44 in.
Wheelbase 2703 mm
106.42 in.
Front track 1498 mm
58.98 in.
Rear (Back) track 1500 mm
59.06 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Coil spring
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
