Specifications: Volkswagen Passat Variant (B7) 2.0 TDI BMT (177 Hp) 2012, 2013, 2014

2010 Volkswagen Passat Variant (B7) - Photo 1

Volkswagen Passat Variant (B7) 2.0 TDI BMT (177 Hp) – Full specifications
General information
Brand Volkswagen
Model Passat
Generation Passat Variant (B7)
Modification (Engine) 2.0 TDI BMT (177 Hp)
Start of production 2012 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 5.6 l/100 km
42 US mpg
50.4 UK mpg
17.9 km/l
Fuel consumption (economy) – extra urban (NEDC) 4.2 l/100 km
56 US mpg
67.3 UK mpg
23.8 km/l
Fuel consumption (economy) – combined (NEDC) 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
CO2 emissions (NEDC) 123 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.6 sec
Acceleration 0 – 62 mph 8.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.2 sec
Maximum speed 224 km/h
139.19 mph
Emission standard Euro 5
Weight-to-power ratio 8.4 kg/Hp, 119.4 Hp/tonne
Weight-to-torque ratio 3.9 kg/Nm, 256.2 Nm/tonne
Engine specs
Power 177 Hp @ 4200 rpm.
Power per litre 89.9 Hp/l
Torque 380 Nm @ 1750-2500 rpm.
280.27 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code EA189 / CFGC
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1483 kg
3269.46 lbs.
Max. weight 2170 kg
4784.03 lbs.
Max load 687 kg
1514.58 lbs.
Trunk (boot) space – minimum 603 l
21.29 cu. ft.
Trunk (boot) space – maximum 1731 l
61.13 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4771 mm
187.83 in.
Width 1820 mm
71.65 in.
Width including mirrors 2062 mm
81.18 in.
Height 1516 mm
59.69 in.
Wheelbase 2712 mm
106.77 in.
Front track 1552 mm
61.1 in.
Rear (Back) track 1551 mm
61.06 in.
Front overhang 941 mm
37.05 in.
Rear overhang 1118 mm
44.02 in.
Ride height (ground clearance) 135 mm
5.31 in.
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Approach angle 13.5°
Departure angle 11.9°
Ramp-over (brakeover) angle 9.5°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 312×25 mm
Rear brakes Disc, 286×12 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/55 R16; 235/45 R17; 235/40 R18
Wheel rims size 7J x 16; 7.5J x 17; 8J x 18
