Specifications: Volkswagen Phideon 380TSI (224 Hp) DSG 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025

2016 Volkswagen Phideon - Photo 1

Volkswagen Phideon 380TSI (224 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Phideon
Generation Phideon
Modification (Engine) 380TSI (224 Hp) DSG
Start of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – combined 7 l/100 km
33.6 US mpg
40.4 UK mpg
14.3 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.1 sec
Acceleration 0 – 62 mph 8.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.7 sec
Maximum speed 240 km/h
149.13 mph
Weight-to-power ratio 8.1 kg/Hp, 123.4 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 192.8 Nm/tonne
Engine specs
Power 224 Hp @ 4500-6250 rpm.
Power per litre 112.9 Hp/l
Torque 350 Nm @ 1500-4500 rpm.
258.15 lb.-ft. @ 1500-4500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA888
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC

Space, Volume and weights
Kerb Weight 1815 kg
4001.39 lbs.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Dimensions
Length 5074 mm
199.76 in.
Width 1893 mm
74.53 in.
Height 1489 mm
58.62 in.
Wheelbase 3009 mm
118.46 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
