Specifications: Volkswagen Polo III Variant 1.9 TDI (110 Hp) 1998, 1999, 2000

1994 Volkswagen Polo III Variant - Photo 1

Volkswagen Polo III Variant 1.9 TDI (110 Hp) – Full specifications
General information
Brand Volkswagen
Model Polo
Generation Polo III Variant
Modification (Engine) 1.9 TDI (110 Hp)
Start of production 1998 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.5 l/100 km
36.2 US mpg
43.5 UK mpg
15.4 km/l
Fuel consumption (economy) – extra urban 4.1 l/100 km
57.4 US mpg
68.9 UK mpg
24.4 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.9 sec
Acceleration 0 – 62 mph 10.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.4 sec
Maximum speed 190 km/h
118.06 mph
Weight-to-power ratio 10.8 kg/Hp, 92.4 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 197.5 Nm/tonne
Engine specs
Power 110 Hp @ 4150 rpm.
Power per litre 58 Hp/l
Torque 235 Nm @ 1900 rpm.
173.33 lb.-ft. @ 1900 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AFN
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 19.5:1
Number of valves per cylinder 2
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt

Space, Volume and weights
Kerb Weight 1190 kg
2623.5 lbs.
Max. weight 1650 kg
3637.63 lbs.
Max load 460 kg
1014.13 lbs.
Trunk (boot) space – minimum 390 l
13.77 cu. ft.
Trunk (boot) space – maximum 1290 l
45.56 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Dimensions
Length 4137 mm
162.87 in.
Width 1640 mm
64.57 in.
Height 1433 mm
56.42 in.
Wheelbase 2444 mm
96.22 in.
Front track 1429 mm
56.26 in.
Rear (Back) track 1384 mm
54.49 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Coil spring
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 185/60 R14
Wheel rims size 14
