Specifications: Volkswagen Sharan I (facelift 2000) 2.8 V6 (204 Hp) 2000, 2001, 2002, 2003, 2004

2000 Volkswagen Sharan I (facelift 2000) - Photo 1

Volkswagen Sharan I (facelift 2000) 2.8 V6 (204 Hp) – Full specifications
General information
Brand Volkswagen
Model Sharan
Generation Sharan I (facelift 2000)
Modification (Engine) 2.8 V6 (204 Hp)
Start of production 2000 year
End of production 2004 year
Powertrain Architecture Internal Combustion engine
Body type Minivan, MPV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 14.8 l/100 km
15.9 US mpg
19.1 UK mpg
6.8 km/l
Fuel consumption (economy) – extra urban (NEDC) 8.5 l/100 km
27.7 US mpg
33.2 UK mpg
11.8 km/l
Fuel consumption (economy) – combined (NEDC) 10.8 l/100 km
21.8 US mpg
26.2 UK mpg
9.3 km/l
CO2 emissions (NEDC) 259 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.9 sec
Acceleration 0 – 62 mph 9.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.4 sec
Maximum speed 217 km/h
134.84 mph
Emission standard Euro 4
Weight-to-power ratio 9.5 kg/Hp, 105.2 Hp/tonne
Weight-to-torque ratio 7.3 kg/Nm, 136.7 Nm/tonne
Engine specs
Power 204 Hp @ 6200 rpm.
Power per litre 73.1 Hp/l
Torque 265 Nm @ 3400 rpm.
195.45 lb.-ft. @ 3400 rpm.
Engine layout Front, Transverse
Engine Model/Code AYL
Engine displacement 2792 cm3
170.38 cu. in.
Number of cylinders 6
Engine configuration VR-engine
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 90.3 mm
3.56 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 5.7 l
6.02 US qt | 5.02 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11 l
11.62 US qt | 9.68 UK qt

Space, Volume and weights
Kerb Weight 1939 kg
4274.76 lbs.
Max. weight 2470 kg
5445.42 lbs.
Max load 531 kg
1170.65 lbs.
Trunk (boot) space – minimum 256 l
9.04 cu. ft.
Trunk (boot) space – maximum 2610 l
92.17 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 700 kg
1543.24 lbs.
Permitted towbar download 85 kg
187.39 lbs.
Dimensions
Length 4634 mm
182.44 in.
Width 1810 mm
71.26 in.
Height 1759 mm
69.25 in.
Wheelbase 2841 mm
111.85 in.
Front track 1530 mm
60.24 in.
Rear (Back) track 1524 mm
60 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson, Transverse stabilizer
Rear suspension Transverse stabilizer, Trailing arm, Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/55 R16
Wheel rims size 7J x 16
