Specifications: Volkswagen Sharan II (facelift 2015) 1.4 TSI (150 Hp) DSG 2015, 2016, 2017, 2018

2015 Volkswagen Sharan II (facelift 2015) - Photo 1

Volkswagen Sharan II (facelift 2015) 1.4 TSI (150 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Sharan
Generation Sharan II (facelift 2015)
Modification (Engine) 1.4 TSI (150 Hp) DSG
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Minivan, MPV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8 l/100 km
29.4 US mpg
35.3 UK mpg
12.5 km/l
Fuel consumption (economy) – extra urban 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel consumption (economy) – combined 6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l
CO2 emissions 154-155 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.9 sec
Acceleration 0 – 62 mph 9.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.4 sec
Maximum speed 198 km/h
123.03 mph
Emission standard Euro 6
Weight-to-power ratio 10.9 kg/Hp, 91.4 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 152.3 Nm/tonne
Engine specs
Power 150 Hp @ 5000-6000 rpm.
Power per litre 107.5 Hp/l
Torque 250 Nm @ 1500-3500 rpm.
184.39 lb.-ft. @ 1500-3500 rpm.
Engine layout Front, Transverse
Engine Model/Code CTHA, CZDA, DJKA
Engine displacement 1395 cm3
85.13 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1642 kg
3619.99 lbs.
Max. weight 2310 kg
5092.68 lbs.
Max load 668 kg
1472.69 lbs.
Trunk (boot) space – minimum 955 l
33.73 cu. ft.
Trunk (boot) space – maximum 2430 l
85.81 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4854 mm
191.1 in.
Width 1904 mm
74.96 in.
Width including mirrors 2081 mm
81.93 in.
Height 1720 mm
67.72 in.
Wheelbase 2920 mm
114.96 in.
Front track 1571 mm
61.85 in.
Rear (Back) track 1617 mm
63.66 in.
Ride height (ground clearance) 155 mm
6.1 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission DSG
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R16; 225/50 R17; 225/45 R18
Wheel rims size 16; 17; 18
