Specifications: Volkswagen Tiguan II Allspace 2.0 TDI (150 Hp) DSG 2016, 2017, 2018

2016 Volkswagen Tiguan II Allspace - Photo 1

Volkswagen Tiguan II Allspace 2.0 TDI (150 Hp) DSG – Full specifications
General information
Brand Volkswagen
Model Tiguan
Generation Tiguan II Allspace
Modification (Engine) 2.0 TDI (150 Hp) DSG
Start of production January, 2016 year
End of production August, 2018 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.7 l/100 km
41.3 US mpg
49.6 UK mpg
17.5 km/l
Fuel consumption (economy) – extra urban 4.5 l/100 km
52.3 US mpg
62.8 UK mpg
22.2 km/l
Fuel consumption (economy) – combined 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
CO2 emissions 129 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.3 sec
Acceleration 0 – 62 mph 9.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.8 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 6
Weight-to-power ratio 11.1 kg/Hp, 90.4 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 204.8 Nm/tonne
Engine specs
Power 150 Hp @ 3500-4000 rpm.
Power per litre 76.2 Hp/l
Torque 340 Nm @ 1750-3000 rpm.
250.77 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code DFGA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.2:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1660 kg
3659.67 lbs.
Max. weight 2320 kg
5114.72 lbs.
Max load 660 kg
1455.05 lbs.
Trunk (boot) space – minimum 230 l
8.12 cu. ft.
Trunk (boot) space – maximum 1775 l
62.68 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
AdBlue tank 12 l
3.17 US gal | 2.64 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4701 mm
185.08 in.
Width 1839 mm
72.4 in.
Width including mirrors 2099 mm
82.64 in.
Height 1674 mm
65.91 in.
Wheelbase 2787 mm
109.72 in.
Front track 1575-1585 mm
62.01 – 62.4 in.
Rear (Back) track 1564-1574 mm
61.57 – 61.97 in.
Ride height (ground clearance) 191 mm
7.52 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Approach angle 16.9°
Departure angle 14.5°
Ramp-over (brakeover) angle 14.9°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R17; 235/55 R18
Wheel rims size 7J x 17; 7J x 18
