Specifications: Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 TDI BMT (140 Hp) DSG L1H1 2012, 2013, 2014, 2015

2010 Volkswagen Transporter (T5, facelift 2009) Kombi - Photo 1

Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 TDI BMT (140 Hp) DSG L1H1 – Full specifications
General information
Brand Volkswagen
Model Transporter
Generation Transporter (T5, facelift 2009) Kombi
Modification (Engine) 2.0 TDI BMT (140 Hp) DSG L1H1
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Van
Seats 4-9
Doors 4-5
Performance specs
Fuel consumption (economy) – urban (NEDC) 9.3 l/100 km
25.3 US mpg
30.4 UK mpg
10.8 km/l
Fuel consumption (economy) – extra urban (NEDC) 6.5 l/100 km
36.2 US mpg
43.5 UK mpg
15.4 km/l
Fuel consumption (economy) – combined (NEDC) 7.5 l/100 km
31.4 US mpg
37.7 UK mpg
13.3 km/l
CO2 emissions (NEDC) 198 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 13 sec
Acceleration 0 – 62 mph 13 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.4 sec
Maximum speed 172 km/h
106.88 mph
Emission standard Euro 5
Weight-to-power ratio 13.6 kg/Hp, 73.6 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 178.9 Nm/tonne
Engine specs
Power 140 Hp @ 3500 rpm.
Power per litre 71.1 Hp/l
Torque 340 Nm @ 1750-2500 rpm.
250.77 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code EA189 / CAAC
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11 l
11.62 US qt | 9.68 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1901 kg
4190.99 lbs.
Max. weight 2800-3200 kg
6172.94 – 7054.79 lbs.
Max load 899-1299 kg
1981.96 – 2863.8 lbs.
Trunk (boot) space – maximum 5800 l
204.83 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2500 kg
5511.56 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4892 mm
192.6 in.
Width 1904 mm
74.96 in.
Width including mirrors 2283 mm
89.88 in.
Height 1990 mm
78.35 in.
Wheelbase 3000 mm
118.11 in.
Front overhang 896 mm
35.28 in.
Rear overhang 996 mm
39.21 in.
Ride height (ground clearance) 201 mm
7.91 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Approach angle 21°
Departure angle 17°
Ramp-over (brakeover) angle 14°
Wading depth 300 mm
11.81 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring, Transverse stabilizer, Trailing arm
Front brakes Ventilated discs, 308×29.5 mm
Rear brakes Ventilated discs, 294×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/65 R16
Wheel rims size 6.5J x 16
