Specifications: Volkswagen Transporter (T5, facelift 2009) Panel Van 2.0 TDI BMT (180 Hp) L1H1 2013, 2014, 2015

2010 Volkswagen Transporter (T5, facelift 2009) Panel Van - Photo 1

Volkswagen Transporter (T5, facelift 2009) Panel Van 2.0 TDI BMT (180 Hp) L1H1 – Full specifications
General information
Brand Volkswagen
Model Transporter
Generation Transporter (T5, facelift 2009) Panel Van
Modification (Engine) 2.0 TDI BMT (180 Hp) L1H1
Start of production 2013 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Van
Seats 2-3
Doors 4-5
Performance specs
Fuel consumption (economy) – urban (NEDC) 8.6-8.9 l/100 km
27.4 – 26.4 US mpg
32.8 – 31.7 UK mpg
11.6 – 11.2 km/l
Fuel consumption (economy) – extra urban (NEDC) 6.1-6.4 l/100 km
38.6 – 36.8 US mpg
46.3 – 44.1 UK mpg
16.4 – 15.6 km/l
Fuel consumption (economy) – combined (NEDC) 7-7.3 l/100 km
33.6 – 32.2 US mpg
40.4 – 38.7 UK mpg
14.3 – 13.7 km/l
CO2 emissions (NEDC) 184-192 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.9 sec
Acceleration 0 – 62 mph 9.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.4 sec
Maximum speed 191 km/h
118.68 mph
Emission standard Euro 5
Weight-to-power ratio 9.8 kg/Hp, 101.8 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 226.1 Nm/tonne
Engine specs
Power 180 Hp @ 4000 rpm.
Power per litre 91.5 Hp/l
Torque 400 Nm @ 1500-2000 rpm.
295.02 lb.-ft. @ 1500-2000 rpm.
Engine layout Front, Transverse
Engine Model/Code EA189 / CFCA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration BiTurbo, Intercooler
Valvetrain DOHC
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11 l
11.62 US qt | 9.68 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1769-2158 kg
3899.98 – 4757.58 lbs.
Max. weight 2800-3200 kg
6172.94 – 7054.79 lbs.
Max load 1031-1042 kg
2272.97 – 2297.22 lbs.
Trunk (boot) space – maximum 5800 l
204.83 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2500 kg
5511.56 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4892 mm
192.6 in.
Width 1904 mm
74.96 in.
Width including mirrors 2283 mm
89.88 in.
Height 1990 mm
78.35 in.
Wheelbase 3000 mm
118.11 in.
Front overhang 896 mm
35.28 in.
Rear overhang 996 mm
39.21 in.
Ride height (ground clearance) 201 mm
7.91 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Approach angle 21°
Departure angle 17°
Ramp-over (brakeover) angle 14°
Wading depth 300 mm
11.81 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring, Transverse stabilizer, Trailing arm
Front brakes Ventilated discs, 340×32.5 mm
Rear brakes Ventilated discs, 294×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/60 R17; 235/55 R17; 255/45 R18
Wheel rims size 7J x 17; 8J x 18
