Specifications: Volkswagen Transporter (T6.1, facelift 2019) Kombi Crew Van 2.0 TDI (150 Hp) 4MOTION L2H1 2021, 2022

2020 Volkswagen Transporter (T6.1, facelift 2019) Kombi Crew Van - Photo 1

Volkswagen Transporter (T6.1, facelift 2019) Kombi Crew Van 2.0 TDI (150 Hp) 4MOTION L2H1 – Full specifications
General information
Brand Volkswagen
Model Transporter
Generation Transporter (T6.1, facelift 2019) Kombi Crew Van
Modification (Engine) 2.0 TDI (150 Hp) 4MOTION L2H1
Start of production 2021 year
End of production 2022 year
Powertrain Architecture Internal Combustion engine
Body type Van
Seats 5-6
Doors 4-5
Performance specs
Fuel consumption (economy) – urban (NEDC, WLTP equivalent) 8.2-8.3 l/100 km
28.7 – 28.3 US mpg
34.4 – 34 UK mpg
12.2 – 12 km/l
Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) 6.1-6.3 l/100 km
38.6 – 37.3 US mpg
46.3 – 44.8 UK mpg
16.4 – 15.9 km/l
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 6.9-7.1 l/100 km
34.1 – 33.1 US mpg
40.9 – 39.8 UK mpg
14.5 – 14.1 km/l
CO2 emissions (NEDC, WLTP equivalent) 181-187 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.3 sec
Acceleration 0 – 62 mph 11.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.7 sec
Maximum speed 180 km/h
111.85 mph
Emission standard Euro 6d-ISC-FCM
Weight-to-power ratio 14.8 kg/Hp, 67.4 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 152.9 Nm/tonne
Engine specs
Power 150 Hp @ 3250-3750 rpm.
Power per litre 76.2 Hp/l
Torque 340 Nm @ 1500-3000 rpm.
250.77 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code EA288MAR / DNAA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 15.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7.4 l
7.82 US qt | 6.51 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 2224-2380 kg
4903.08 – 5247 lbs.
Max. weight 3000-3200 kg
6613.87 – 7054.79 lbs.
Max load 776-820 kg
1710.79 – 1807.79 lbs.
Trunk (boot) space – maximum 4400 l
155.38 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
AdBlue tank 22 l
5.81 US gal | 4.84 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2500 kg
5511.56 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 5304 mm
208.82 in.
Width 1904 mm
74.96 in.
Width including mirrors 2297 mm
90.43 in.
Height 1990 mm
78.35 in.
Wheelbase 3400 mm
133.86 in.
Front overhang 906 mm
35.67 in.
Rear overhang 998 mm
39.29 in.
Ride height (ground clearance) 202 mm
7.95 in.
Minimum turning circle (turning diameter) 13.2 m
43.31 ft.
Approach angle 21.2°
Departure angle 16.2°
Ramp-over (brakeover) angle 12.2°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring, Wishbone, Transverse stabilizer
Front brakes Ventilated discs, 308×29.5 mm
Rear brakes Ventilated discs, 294×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/65 R16; 215/65 R16
Wheel rims size 6.5J x 16
