Specifications: Volkswagen Transporter (T6) Panel Van 2.0 TDI (180 Hp) 4MOTION DSG L2H2 2015, 2016

2016 Volkswagen Transporter (T6) Panel Van - Photo 1

Volkswagen Transporter (T6) Panel Van 2.0 TDI (180 Hp) 4MOTION DSG L2H2 – Full specifications
General information
Brand Volkswagen
Model Transporter
Generation Transporter (T6) Panel Van
Modification (Engine) 2.0 TDI (180 Hp) 4MOTION DSG L2H2
Start of production 2015 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Van
Seats 2-3
Doors 4-5
Performance specs
Fuel consumption (economy) – urban (NEDC) 9.4-9.7 l/100 km
25 – 24.2 US mpg
30.1 – 29.1 UK mpg
10.6 – 10.3 km/l
Fuel consumption (economy) – extra urban (NEDC) 7.2-7.5 l/100 km
32.7 – 31.4 US mpg
39.2 – 37.7 UK mpg
13.9 – 13.3 km/l
Fuel consumption (economy) – combined (NEDC) 8-8.3 l/100 km
29.4 – 28.3 US mpg
35.3 – 34 UK mpg
12.5 – 12 km/l
CO2 emissions (NEDC) 211-219 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.7 sec
Acceleration 0 – 62 mph 10.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.2 sec
Maximum speed 182 km/h
113.09 mph
Emission standard Euro 5
Weight-to-power ratio 10.7 kg/Hp, 93.2 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 207 Nm/tonne
Engine specs
Power 180 Hp @ 4000 rpm.
Power per litre 91.5 Hp/l
Torque 400 Nm @ 1500-2500 rpm.
295.02 lb.-ft. @ 1500-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code EA189 / CFCA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration BiTurbo, Intercooler
Valvetrain DOHC
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1932-2249 kg
4259.33 – 4958.2 lbs.
Max. weight 2800-3200 kg
6172.94 – 7054.79 lbs.
Max load 868-951 kg
1913.61 – 2096.6 lbs.
Trunk (boot) space – maximum 7800 l
275.45 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2500 kg
5511.56 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 5304 mm
208.82 in.
Width 1904 mm
74.96 in.
Width including mirrors 2297 mm
90.43 in.
Height 2170 mm
85.43 in.
Wheelbase 3400 mm
133.86 in.
Front overhang 908 mm
35.75 in.
Rear overhang 993 mm
39.09 in.
Ride height (ground clearance) 202 mm
7.95 in.
Minimum turning circle (turning diameter) 13.2 m
43.31 ft.
Approach angle 21.2°
Departure angle 16.2°
Ramp-over (brakeover) angle 12.2°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission DSG
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring, Wishbone, Transverse stabilizer
Front brakes Ventilated discs, 308×29.5 mm
Rear brakes Ventilated discs, 294×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/65 R16; 235/55 R17
Wheel rims size 6.5J x 16; 7J x 17
