| General information | |
|---|---|
| Brand | Volvo |
| Model | 1800 |
| Generation | 1800S |
| Modification (Engine) | 1.8 (108 Hp) |
| Start of production | 1963 year |
| End of production | 1965 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Coupe |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 175 km/h 108.74 mph |
| Weight-to-power ratio | 10.4 kg/Hp, 96.4 Hp/tonne |
| Weight-to-torque ratio | 7.5 kg/Nm, 133 Nm/tonne |
| Engine specs | |
| Power | 108 Hp @ 5800 rpm. |
| Power per litre | 60.7 Hp/l |
| Torque | 149 Nm @ 4000 rpm. 109.9 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | B18B |
| Engine displacement | 1780 cm3 108.62 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84.14 mm 3.31 in. |
| Piston Stroke | 80 mm 3.15 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHV |
| Engine oil capacity | 3.75 l 3.96 US qt | 3.3 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9 l 9.51 US qt | 7.92 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1120 kg 2469.18 lbs. |
| Max. weight | 1400 kg 3086.47 lbs. |
| Max load | 280 kg 617.29 lbs. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 4400 mm 173.23 in. |
| Width | 1700 mm 66.93 in. |
| Height | 1285 mm 50.59 in. |
| Wheelbase | 2450 mm 96.46 in. |
| Front track | 1315 mm 51.77 in. |
| Rear (Back) track | 1315 mm 51.77 in. |
| Ride height (ground clearance) | 155 mm 6.1 in. |
| Minimum turning circle (turning diameter) | 10 m 32.81 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Coil spring, Wishbone, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Tires size | 165/80 R15 |
| Wheel rims size | 4.5J x 15 |
