Specifications: Volvo C30 2.4 i 20V (170 Hp) Automatic 2006, 2007, 2008, 2009, 2010

2007 Volvo C30 - Photo 1

Volvo C30 2.4 i 20V (170 Hp) Automatic – Full specifications
General information
Brand Volvo
Model C30
Generation C30
Modification (Engine) 2.4 i 20V (170 Hp) Automatic
Start of production 2006 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 3
Performance specs
Fuel consumption (economy) – urban 13.1 l/100 km
18 US mpg
21.6 UK mpg
7.6 km/l
Fuel consumption (economy) – extra urban 6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l
Fuel consumption (economy) – combined 9 l/100 km
26.1 US mpg
31.4 UK mpg
11.1 km/l
CO2 emissions 214 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.8 sec
Acceleration 0 – 62 mph 8.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.4 sec
Maximum speed 220 km/h
136.7 mph
Weight-to-power ratio 8.4 kg/Hp, 119 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 161 Nm/tonne
Engine specs
Power 170 Hp @ 6000 rpm.
Power per litre 69.8 Hp/l
Torque 230 Nm @ 4400 rpm.
169.64 lb.-ft. @ 4400 rpm.
Engine layout Front, Transverse
Engine Model/Code B5244S4
Engine displacement 2435 cm3
148.59 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10 l
10.57 US qt | 8.8 UK qt

Space, Volume and weights
Kerb Weight 1429 kg
3150.41 lbs.
Max. weight 1840 kg
4056.51 lbs.
Max load 411 kg
906.1 lbs.
Trunk (boot) space – minimum 233 l
8.23 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4252 mm
167.4 in.
Width 1782 mm
70.16 in.
Height 1447 mm
56.97 in.
Wheelbase 2640 mm
103.94 in.
Front track 1548 mm
60.94 in.
Rear (Back) track 1544 mm
60.79 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
