| General information | |
|---|---|
| Brand | Volvo |
| Model | EC40 |
| Generation | EC40 |
| Modification (Engine) | 70 kWh (238 Hp) Single Motor |
| Start of production | February, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Coupe, SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 7.3 sec |
| Acceleration 0 – 62 mph | 7.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 6.9 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Weight-to-power ratio | 8.6 kg/Hp, 115.7 Hp/tonne |
| Weight-to-torque ratio | 4.9 kg/Nm, 204.2 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 70 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 487 km 302.61 mi |
| Average Energy consumption (WLTP) | 16.7 kWh/100 km
26.88 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 238 Hp |
| Electric motor Torque | 420 Nm
309.78 lb.-ft. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 238 Hp |
| System torque | 420 Nm 309.78 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2057 kg 4534.91 lbs. |
| Max. weight | 2460 kg 5423.37 lbs. |
| Max load | 403 kg 888.46 lbs. |
| Trunk (boot) space – minimum | 404 l 14.27 cu. ft. |
| Trunk (boot) space – maximum | 1205 l 42.55 cu. ft. |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Dimensions | |
| Length | 4440 mm 174.8 in. |
| Width | 1873 mm 73.74 in. |
| Width with mirrors folded | 1938 mm 76.3 in. |
| Width including mirrors | 2034 mm 80.08 in. |
| Height | 1596 mm 62.83 in. |
| Wheelbase | 2702 mm 106.38 in. |
| Front track | 1598 mm 62.91 in. |
| Rear (Back) track | 1603 mm 63.11 in. |
| Front overhang | 870 mm 34.25 in. |
| Rear overhang | 868 mm 34.17 in. |
| Ride height (ground clearance) | 171 mm 6.73 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 235/50 R19 Rear wheel tires: 255/45 R19 |
| Wheel rims size | Front wheel rims: 19 Rear wheel rims: 19 |
