Specifications: Volvo S40 II (facelift 2007) 2.0i (145 Hp) 2007, 2008, 2009, 2010, 2011

2007 Volvo S40 II (facelift 2007) - Photo 1

Volvo S40 II (facelift 2007) 2.0i (145 Hp) – Full specifications
General information
Brand Volvo
Model S40
Generation S40 II (facelift 2007)
Modification (Engine) 2.0i (145 Hp)
Start of production April, 2007 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 10.2 l/100 km
23.1 US mpg
27.7 UK mpg
9.8 km/l
Fuel consumption (economy) – extra urban 5.7 l/100 km
41.3 US mpg
49.6 UK mpg
17.5 km/l
Fuel consumption (economy) – combined 7.4 l/100 km
31.8 US mpg
38.2 UK mpg
13.5 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.5 sec
Acceleration 0 – 62 mph 9.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 4
Weight-to-power ratio 8.9 kg/Hp, 111.9 Hp/tonne
Weight-to-torque ratio 7 kg/Nm, 142.7 Nm/tonne
Engine specs
Power 145 Hp @ 6000 rpm.
Power per litre 72.5 Hp/l
Torque 185 Nm @ 4500 rpm.
136.45 lb.-ft. @ 4500 rpm.
Engine layout Front, Transverse
Engine Model/Code B4204S3
Engine displacement 1999 cm3
121.99 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 87.5 mm
3.44 in.
Piston Stroke 83.1 mm
3.27 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Kerb Weight 1296 kg
2857.19 lbs.
Trunk (boot) space – minimum 404 l
14.27 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4468 mm
175.91 in.
Width 1770 mm
69.69 in.
Height 1452 mm
57.17 in.
Wheelbase 2640 mm
103.94 in.
Front track 1531 mm
60.28 in.
Rear (Back) track 1535 mm
60.43 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Assisting systems ABS (Anti-lock braking system)
