Specifications: Volvo S60 2.4i T5 20V (260 Hp) 2005, 2006, 2007, 2008, 2009

2001 Volvo S60 - Photo 1

Volvo S60 2.4i T5 20V (260 Hp) – Full specifications
General information
Brand Volvo
Model S60
Generation S60
Modification (Engine) 2.4i T5 20V (260 Hp)
Start of production 2005 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 12.7 l/100 km
18.5 US mpg
22.2 UK mpg
7.9 km/l
Fuel consumption (economy) – extra urban 7.3 l/100 km
32.2 US mpg
38.7 UK mpg
13.7 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.5 sec
Acceleration 0 – 62 mph 6.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.2 sec
Maximum speed 250 km/h
155.34 mph
Weight-to-power ratio 5.8 kg/Hp, 171.1 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 230.3 Nm/tonne
Engine specs
Power 260 Hp @ 5500 rpm.
Power per litre 108.3 Hp/l
Torque 350 Nm @ 2100 rpm.
258.15 lb.-ft. @ 2100 rpm.
Engine layout Front, Transverse
Engine Model/Code B5244T5
Engine displacement 2401 cm3
146.52 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 93.2 mm
3.67 in.
Compression ratio 8.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.8 l
9.3 US qt | 7.74 UK qt

Space, Volume and weights
Kerb Weight 1520 kg
3351.03 lbs.
Max. weight 2025 kg
4464.36 lbs.
Max load 505 kg
1113.33 lbs.
Trunk (boot) space – minimum 424 l
14.97 cu. ft.
Trunk (boot) space – maximum 1034 l
36.52 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4576 mm
180.16 in.
Width 1804 mm
71.02 in.
Height 1428 mm
56.22 in.
Wheelbase 2715 mm
106.89 in.
Front track 1563 mm
61.54 in.
Rear (Back) track 1560 mm
61.42 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Wishbone
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/55 R16
Wheel rims size 16
